Bash: UT-Citrix


I developed the Ubuntu version Citrix thin client. To follow the same naming convention as TC-Citrix, I name it UT-Citrix.


Here are the key scripts:

checkip

#!/bin/bash

#wait for the DHCP ready
while ! ifconfig eth0 | grep ‘inet addr’ >/dev/null 2>&1
do
echo
sleep 2
done

sysprep

#!/bin/bash
#rename the computer
echo
HOSTNAME=UT-`ifconfig | grep ‘eth0’ | tr -s ‘ ‘ | cut -d ‘ ‘ -f5 | sed ‘s/://g’`
rm -f /etc/hostname
echo $HOSTNAME > /etc/hostname
hostname -F /etc/hostname
rm -f /etc/hosts
echo “127.0.0.1 localhost” > /etc/hosts
echo “127.0.0.1 $HOSTNAME” >> /etc/hosts

#generate new SSH key
rm /etc/ssh/ssh_host_*
dpkg-reconfigure openssh-server

sleep 3

launch_ica

#!/bin/bash

#check hostname if not running from CD-ROM
HOSTNAME=UT-`ifconfig | grep ‘eth0’ | tr -s ‘ ‘ | cut -d ‘ ‘ -f5 | sed ‘s/://g’`
PC=`hostname`
if [ -d /rofs ]; then
echo “running from live CD”
sudo hostname $HOSTNAME
elif [ $PC != $HOSTNAME ]; then
sudo /usr/local/sw/sysprep | zenity –progress –pulsate –text=”Computer needs to be renamed at the first time, reboot shortly…” –auto-close –no-cancel
sudo reboot
else
echo “The PC name is correct.”
fi

#wait for network ready
/usr/local/sw/checkip | zenity –progress –pulsate –text=”Network is initializing, please wait…” –auto-close –no-cancel

#check the IP address 10.* or 192.* or 172.*
ip=`ifconfig eth0 | grep ‘inet addr’ | cut -d’:’ -f2 | cut -d’ ‘ -f1 | cut -d’.’ -f1`
while [[ “$ip” != “10” && “$ip” != “192” && “$ip” != “172” ]];
do
ip1=`ifconfig eth0 | grep ‘inet addr’ | cut -d’:’ -f2 | cut -d’ ‘ -f1`
zenity –error –text=”Invalid IP address: $ip1 \n\nPlease check your network settings.” –no-wrap
sleep 5
ip=`ifconfig eth0 | grep ‘inet addr’ | cut -d’:’ -f2 | cut -d’ ‘ -f1 | cut -d’.’ -f1`
done

# check the timezone
sudo chmod 777 /etc/timezone
location=`cat $(ls -t /var/lib/dhcp/*eth0* | head -1) | grep ftp-root | cut -d’ ‘ -f5 | cut -d’\’ -f3`
case $location in
act|vic|nsw|qld|tas)
echo “You are in EST”
sudo echo “Australia/Sydney” > /etc/timezone
sudo cp -f /usr/share/zoneinfo/Australia/NSW /etc/localtime
;;
sa|nt)
echo “You are in CST”
sudo echo “Australia/Adelaide” > /etc/timezone
sudo cp -f /usr/share/zoneinfo/Australia/South /etc/localtime
;;
wa)
echo “You are in WST”
sudo echo “Australia/Perth” > /etc/timezone
sudo cp -f /usr/share/zoneinfo/Australia/West /etc/localtime
;;
*)
zenity –error –text=”Failed to detect your timezone, please set it manually.” –no-wrap
gnome-control-center indicator-datetime
;;
esac

# Wait for ica
sleep 1
(for((i=0; i<=100; i+=25)); do sleep 1 && echo $i; done;) | zenity –progress –text=”Launching Citrix client…” –auto-close –no-cancel
#xdotool search –name “Citrix Receiver” windowactivate –sync key –clearmodifiers Alt+F9 &

#launch ica authentication
/opt/Citrix/ICAClient/wfcmgr

#remove last user’s desktop cache
rm -rf /home/generic/Desktop/*
#rm -rf /home/generic/.ICAClient/cache/Desktop/*
#rm -rf /home/generic/.ICAClient/cache/Programs/*

# shutdown computer
sudo poweroff

~/.conkyrc (conky conf file)

# Conky configuration
alignment top_right
background yes
use_xft yes
xftfont Monospace:size=9
xftalpha 0.8
out_to_console no
update_interval 2
total_run_times 0
own_window yes
own_window_type normal
own_window_transparent yes
own_window_hints undecorated,below,sticky,skip_taskbar,skip_pager
double_buffer yes
draw_shades no
draw_outline no
draw_borders no
draw_graph_borders yes
stippled_borders 5
border_margin 4
border_width 1
default_color grey
default_shade_color black
default_outline_color black
alignment top_right
gap_x 10
gap_y 47
no_buffers no
uppercase no
cpu_avg_samples 2
net_avg_samples 2
override_utf8_locale yes
use_spacer no

TEXT
${alignc}${color white}SERVICE DESK SUPPORT
${alignc}${color white}XXXX XXX XXX
$color$stippled_hr
${color}Date: ${color white}${time %A,%d %B}
${color}Time: ${color white}${time %k:%M:%S}
${color}Timezone: ${color white}${exec date | cut -d’ ‘ -f6}
$color$stippled_hr
${color}Hostname: ${color white}$nodename
${color}Uptime: ${color white}$uptime
${color}CPU:${color white} ${cpu cpu0}% ${cpubar cpu0}
${color}RAM:${color white} $memperc%  $mem/$memmax $membar
${color}Swap: ${color white}$swapperc% $swap/$swapmax ${swapbar}
${color}HDD:${color white} ${fs_used_perc /}% ${fs_used /}/${fs_size /} ${fs_bar /}
${color}IP: ${color white}$alignc${exec ifconfig eth0 | grep ‘inet addr’ | cut -d’:’ -f2 | cut -d’ ‘ -f1}

Advertisement

2 thoughts on “Bash: UT-Citrix

  1. Can you give more details on how to create this Ubuntu based thin client? Also, can you include how to make it a PXE bootable package?

    1. Hi Douglas, I have wrote comments for each section. So just spend some time to understand what the script does, and you may need to modify some of them to fit your environment.
